The main function of the fiber storage machine is to store fiber to ensure continuous supply to subsequent non woven soft wadding production line and thermal bonded production line or needle punching production lines.
After preliminary mixing, the fibers are fed into the upper fiber collection box of the machine through the conveying fan, which is achieved through a feeding pipe. The fibers are sent to the opening roller through the upper feeding roller for further opening, and then fall into the lower fiber collection box., during which the fibers will be mixed again. After passing through the vibrating screen, the fiber layer enters the next process.
Working Width:1600mm-2000mm
Weight: About 1600-2500KG
Output: 150-800KG/H
Total Power: About 5-6 KW
Main Features:
(1)The wallboard is made of high-quality steel plate folded plate, the inner wall is smooth without burr, hanging fiber or rust;
(2)The machine is equipped with photoelectric sensors in many places to control the storage quantity and make the raw materials mix evenly.
(3)The fiber inlet is equipped with a condenser to absorb dust;
